Comprehensive kit to service your rocker covers.
Kit Contents:(1996-2000/08)
4 x PLUG, SEMICIRCULAR
2 x PLUG, CAMSHAFT HOUSING
6 x GASKET, SPARK PLUG TUBE
2 x GASKET, CYLINDER HEAD COVER
1 x GASKET(FOR OIL FILLER CAP)
1 x VALVE SUB-ASSY, VENTILATION
0 x GROMMET(FOR VENTILATION SYSTEM) (grommet out of stock)
2 x GASKET, AIR SURGE TANK TO INTAKE MANIFOLD
1 x GASKET, THROTTLE BODY
16 x STD PART (Washer/grommet for bolt)
(2000/09 (VIN required))
Contents will be similar, with only slight changes for compatibility.
(2000/10 onwards)
Contents will be similar, with only slight changes for compatibility.
| Part Information | |
| Toyota Part Code(s) | 11183, 11188, 11193, 11193A, 11213, 11214, 12108A, 12204, 12204A, 17176, 17176A, 22271 |
| Compatibility Notes | |
| Catalog page reference(s) | 11-04, 12-01, 17-01, 22-11 |
| Kit was compiled for | Prado 90 Series with 5VZ engine. |
Rocker Cover Kit
- Brand: Toyota
- Product Code: 5VZ_rocker3
- Availability: Out of stock
-
$273.00
Available Options
Tags: 11183, 11188, 11193, 11193A, 11213, 11214, 12108A, 12204, 12204A, 17176, 17176A, 22271, 11-04, 12-01, 17-01, 22-11
